Model

KF1100-I

Power

1200W

Chamber size

100X100X100mm（LXWXH）

Dimension

220X270X380mm（LXWXH）

Voltage

220V,50/60HZ

Max. Temp.

1100°C max for an hour

Working temp.

≤1000°C

Thermocouple

K type

 Heating element

Resistance wire

Heating rate

20°C/min , suggest ≤10°C/min

Temp. controller

· PID automatic control and auto-tune function.

· 30 programmable segments for precise control.

· Built-in protection for the over-heating and broken thermocouple.

· Large digital control panel (48 x 96 mm) for easy operation.

Surface temp.

  ≤45℃

Warranty

One-year limited warranty with lifetime support

(Any damages caused by the use of corrosive and acidic gasses are not covered by the Warranty.)
