Model

PC-600ZE

Heating temperature

RT-300℃

RT-500℃

Power

3KW

4.5 KW

Pressure range

0-15T

Pressure Accuracy

0.01 Ton

Vacuum degree

-0.1MPa

Vacuum chamber material

SS304

Display screen

7” touch screen

Pressurization process

Manual pressurization

Heating method

Multi-stage Heating or Cooling Program

Holding time

≥1S

Heating insulation method

Imported Heating insulation board

Heating area

Double platens heating 300×300mm (m×n)

Working space

300×70mm

Chamber hatch size

450×350mm(M×N)

Vacuum pump part

490×230×340mm

Weight :20kg

Pressing part dimension

Dimension: 550×650×800mm (L×W×H)

Net weight: 420Kg

Packing Size:725×620×1090mm

Gross weight :456 Kg

Voltage

220V

Diagram of hydraulic press
