Model

PC-2

Pressure range

0-2T

Piston diameter

Φ32mm (d)

Integral structure

No sealing connection, oil leakage reduced

Pressure gauge

Pressure and pressure intensity display

Lifting height of cylinder

30mm (T) Max.

Pressure stability

≤1MPa/10min

Workbench diameter

Φ80mm (D)

Number of columns

Two

Working space

85*120mm (M*N)

Dimension

210*155*360mm (W*L*H)

Weight

20Kg

Diagram of hydraulic press size
