Material

Aluminum 99.99%

Length

48mm

Width

4mm

Thickness

0.09mm in Aluminum Tab

0.28mm in Aluminum Tab with Adhesive Polymer Tape

Max. Loading Current

3A

Net Weight

60mg/pcs

Gross Wight

15g (Tabs with Box)

Pre-taped

Adhesive Polymer Tape on the tab allows for immediate hot sealing
Height of Tape Area: 4.30 mm +/- 0.50 mm

Application

1. Connect to cathode current collector as polymer battery positive terminal
2. Suggested Sealing Method: (parameter below may vary from case to case)
    - Soft type heat-sealing blade (Blade with rubber)
    - 180-200C for upper blade
    - 160-180C for lower blade
    - 40PSI (0.3Mpa)
    - 3 seconds heating time
Adhesive Polymer Tape on the tab allows for immediate hot sealing
