Model

PC-600CZ

Heating temperature

RT-300℃

RT-500℃

RT-800℃

Power

0.6 KW

1 KW

3.5 KW

Pressure range

0-5T

Pressure Accuracy

0.01 Ton

Vacuum degree

-0.1MPa

Vacuum chamber material

SS304

Display screen

7” touch screen

Pressurization process

Manual pressurization

Heating method

Multi-stage Heating or Cooling Program

Holding time

≥1S

Heating insulation method

Imported Heating insulation board

Heating area

Double platens heating 120×120mm (m×n)

Working space

120×55mm

Chamber size

200×200mm(M×N)

Vacuum pump part

490×230×340mm

Weight :20kg

Pressing part dimension

Dimension: 400×450×700mm (L×W×H)

Net weight: 160Kg

Packing Size:725×620×890mm

Gross weight :196 Kg

Voltage

110V / 220V

Diagram of hydraulic press
