Substrate dimension

5-200mm

Speed range

1-12000RPM

Speed accuracy

1RPM

Speed stability

±0.1%

Acceleration range

1-10000RPM/S

Rotate direction

Forward and reverse can be switched

Glue uniformity

±1%

Heating parameters

Index

Temperature control range

Room temperature-200℃

Heating rate (chamber temperature)

To 100℃(1S)、to 200℃(2S)

Cooling rate (chamber temperature)

To room temperature (2S) Glue

Control signal

Index

HMI

8” touch screen

Communication Interface

USB (standard)//RS485(optional)/Bluetooth(standard)

Stylus pen

BAMBOO Resistance pen (standard)

Third party options

Logitech Wireless Mouse/Wireless Keyboard/Kingston 2G Disk

Vacuum pump

SC-550VOil-free pump/FY Oil pump

Program Mode

Parameter

Data setting

Unlimited groups data

Each group of 15 speeds (standard) or unlimited speed (optional)

Each time

0-10000 MIN

Data storage

Unlimited groups data

Data protection

Default with power-down protection

Electrical parameters

Index

Spin coater AC power port

AC100-250V

Vacuum pump AC power port

AC220V(standard) AC110V(optional)

Spin coater power

650W

Vacuum pump power

350W

Vacuum pump pumping speed

≥60L/MIN

Size of machine

Parameter

Dimension

340mm(W)X500mm(D)X250mm(H)

Weight

18KG

Pump weight

9KG

External factor

Parameter

Ambient temperature

0-40℃

Relative humidity

< 85%

Placed on the table

The level of the machine can be adjusted by the built-in spirit level

Technical support

Index

Warranty

1 year
