Model

PC-2N

Pressure range

0-2T(0-25MPa)

Piston diameter

Ф32mm(d)

Integral structure

No sealing connection oil leakage reduce

Pressure gauge

Force and pressure dual scale display

Standard crimping die

One set of crimping die for CR2032, CR2025, and CR2016 is included

Crimping die optional

CR16/CR20/CR24/CR30, etc.

Sealing pressure

0.8-1.2T

Disassembling die optional

CR16/CR20/CR24/CR30, etc.

Disassembling pressure

Within 0.4T

Dimension

210×165×290mm (L×W×H)

Net weight

12Kg
