Model |
TCHGF12Q-I |
TCHGF12Q-II |
TCHGF12Q-III |
TCHGF12Q-IV |
|
Power |
4KW |
5KW |
9KW |
15KW |
|
Chamber size (DXWXH mm) |
300X200X200 |
300X250X250 |
400X300X300 |
500X400X400 |
|
Dimension(mm) |
564X615X905 |
594X625X975 |
634X725X1025 |
764X877X1185 |
|
Voltage |
220V, 50/60Hz |
380V, 50/60Hz |
||
|
Phase |
Single phase |
Three phase |
||
|
Max. Temp. |
1200 ℃ |
|||
|
Working temp. |
≤1100 ℃ |
|||
|
Heating element |
Resistance wire |
|||
|
Temp. controller |
· PID automatic control and auto-tune function. · 30 programmable segments for precise control. · Built-in protection for the over-heating and broken thermocouple. · Large digital control panel for easy operation. |
|||
|
Heating rate |
30 ℃/ Min Max. Suggest ≤15 ℃/ Min |
|||
|
Thermocouple |
K type |
|||
|
Vacuum degree |
-0.1MPa in cold state |
|||
|
Surface temp. |
≤45 ℃ |
|||
|
Vacuum pump |
Optional parts, please order with extra cost |
|||
|
Warranty |
1 year |
|||
