Model

TCHGF14Q-I

TCHGF14Q-II

TCHGF14Q-III

TCHGF14Q-IV

TCHGF14Q-V

Power

3KW

5KW

7KW

9KW

13KW

Chamber size

(DXWXH)

160X150X150

200X200X200

300X200X200

300X250X250

400X300X300

Dimension(mm)

550X515X905

590X555X995

590X655X985

640X655X1035

690X715X1125

Voltage

220V, 50/60HZ

380V, 50/60Hz

Max. Temp.

1200 ℃

Working temp.

 ≤1100 ℃

Heating element

  Resistance wire

Temp. controller

· PID automatic control and auto-tune function.

· 30 programmable segments for precise control.

· Built-in protection for the over-heating and broken thermocouple.

· Large digital control panel for easy operation.

· Temperature accuracy:  +/- 1 ℃

Heating rate

30 ℃/ Min Max. Suggest ≤15 ℃/ Min

Thermocouple

K type

Vacuum degree

-0.1MPa in cold state

Surface temp.

≤45 ℃

Vacuum pump

Optional parts, please order with extra cost

Warranty

1 year

Atmosphere

Max. Working temperature

Air

1400℃

Vacuum

900-1100℃

N2

1270℃

H2

1100℃

Ar

1300℃
