Parameters:
|
Model |
PCD-150S |
|
Pressure range |
0-150.0T(0-33Mpa) |
|
Piston diameter |
Φ250mm (d) |
|
Working process |
Programmed pressure relief |
|
Pressure holding time |
0-999.59 Sec. |
|
Intensity conversion |
Automatic conversion of die pressure |
|
LCD |
4.3” |
|
Equipment protection |
Steel plate equipped with plexiglass door |
|
Lifting height of cylinder |
50mm (T) Max. |
|
Working space |
285*460mm (M*N) |
|
Dimension |
950*600*1100mm (W*L*H) |
|
Voltage |
220V , 50/60Hz |
|
Weight |
620Kg |
|
Diagram of hydraulic press size |
 |
