Model |
TCHKF1700-I |
TCHKF1700-II |
TCHKF1700-III |
TCHKF1700-IV |
TCHKF1700-V |
|
Chamber size (DXWXH mm) |
160X150X150 |
200X200X200 |
300X200X200 |
300X250X250 |
400X300X300 |
|
Power |
3Kw |
5Kw |
7Kw |
9Kw |
13Kw |
|
Voltage |
220V |
220V |
220V |
380V |
380V |
|
Max. Temp. |
1700℃ |
||||
|
Working temp. |
≤1600℃ |
||||
|
Heating element |
MoSi2 rods |
||||
|
Thermocouple |
B type |
||||
|
Heating rate |
≤20℃/min suggest heating rate：≤10℃/min |
||||
|
Temp. controller |
· FA-YD518P-AG temperature controller is included. · Proportional–integral–derivative control (PID control) and auto-tune function · 30 segments programmed with ramping, cooling and dwelling steps · Built-in over-temperature alarm and thermocouple failure alarm · +/- 1 ºC temperature control accuracy · Default DB9 PC communication port · MET Certified |
||||
|
Warranty |
One year limited warranty with lifetime support. (Consumable parts such as sample plates and heating elements are not covered by the warranty) ATTENTION: Any damages caused by the use of corrosive and acidic gases are not under the coverage of One Year Limited Warranty. |
||||
