Model

TCHSJF1700-I

TCHSJF1700-II

TCHSJF1700-III

Power

5.2KW

9KW

12KW

Chamber size

(DXWXH)

200X200X200mm

250X250X250mm

300X300X300mm

Dimension

(DXWXH)

700X700X1950mm

800X800X2100mm

900X900X2200mm

Net weight

265

280

310

Voltage

220V

220V

380V

Max. Temp.

1700°C max for an hour

Working temp.

≤1600°C

Thermocouple

B type

 Heating element

MoSi2 rods

Heating rate

20°C/min , suggest ≤10°C/min

Lifting rate

420mm/ Min

Temp. controller

· PID automatic control and auto-tune function.

· 30 programmable segments for precise control.

· Built-in protection for the over-heating and broken thermocouple.

· Large digital control panel for easy operation.

Surface temp.

  ≤45℃

Warranty

One-year limited warranty with lifetime support

(Any damages caused by the use of corrosive and acidic gasses are not covered by the Warranty.)
