Model

PC-24

Pressure range

0-24T(0-34Mpa)

Piston diameter

Φ95mm (d)

Integral structure

No sealing connection, oil leakage reduced

Pressure gauge

Pressure and pressure intensity display

Lifting height of cylinder

30mm (T) Max.

Pressure stability

≤1MPa/10min

Workbench diameter

Φ105mm (D)

Number of columns

Four

Working space

80*150mm (M*N)

Dimension

250*175*415mm (W*L*H)

Weight

42Kg

Diagram of hydraulic press size
