Model

PM-PLUS

Voltage

380V ,3 Phase，50Hz

Power

1500W

Time setting

0-1999S

Grinding disc speed

960-1480 r/min

Controller

Touch screen panel

Control device

Digital display time controller/master switch/push button switch

Emergency stop when opening the cover

Yes

Motor phase loss / overcurrent protection

Yes

Slow start and brake stop

No

Grinding disc

three-speed integrated

Four-station grinding disc

Optional

Grinding disc pressing device

adjustable quick pressing

Standard grinding disc

Material: High-chrome steel

Capacity: 500ml

Optional gringding disc

50ml /150ml/500ml/800ml/1000ml

Equipment cable

3 live wires + 1 ground wire

Dimension

680×620×890mm

Net weight

150kg

Packing information

750×690×1010mm / 180kg

Efficiency Performance Reference

Sample: Ore

Weight: 105g

Particle Size: ≤13 mm

Mohs Hardness: ≈6

Grinding Time: 90s

Grinding Rate: 960 rpm

Grinding Disc Specifications: High-chromium Steel 500ml

Output Particle Size: ≤0.074mm
